ICO BS-1600 lamination line

including two unwinders and one rewinder, max line speed: 200 m/min, max roll dia - 1400 mm, max roll weight - 1000 kgs.
Adhesive application weight range; 1 - 100 gsm, with compatible hotmelt types of PSA, PUR, and EVA. UV-added adhesive tank capacity - 100 kgs. 6*heated hoses, 72*applicator/nozzles, 10*heating zones, BST web-guiding system EKR 500 and digital edge control CLS Pro 600. Siemens PLC and HMI with touch screen.
Applications: Nonwoven, PET, metalized OPP, printed PET and metalized PET
